R-DRG-V Ring collated nails with fuel cells and two types of valves in box - galvanised
Features and benefits
- 34º angle collation with a clipped head ensures the nail is compatible with all leading manufactures tools
- Special coating at the base of the shank improves the drive of the nail and ensures a secure fixing
- Diamond point prevents the timber from splitting
- Waxed paper collation avoids deterioration in wet conditions
- 12um zinc coating provides protection according to Eurocode 5, service class 2 compliant
- Depending on the quantity of nails box contains 1,2 or 3 fuel cells
- A wide variety of combinations of nail coatings and finishes wllows everyone to find the right solution for a particular application
Applications
- Timber frame stud work in timber framing industry
- Installation of battens and sheating in roof construction
- Installation of soffits and other roof finishing elements
- Installation of wooden facades
- Installation of timber flooring and terraces
- Manufacturing of timber standarised structure like Timber frame houses or roof elements
Product information
|
Index |
Fastener diameter |
Length |
Head type |
Shank type |
Finish |
Protection |
Collation |
Fasteners per strip |
Carton quantity |
Fuel cells per carton |
Box weight |
Outer weight |
EAN |
|
[mm] |
[mm] |
[pcs] |
[pcs] |
[pcs] |
kg |
kg |
|||||||
|
R-DRG-2851-V |
2.8 |
51 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
3300 |
3 |
9.00 |
9.00 |
5906675464152 |
|
R-DRG-2863-V |
2.8 |
63 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
3300 |
3 |
11.00 |
11.00 |
5906675464169 |
|
R-DRG-2870-V |
2.8 |
70 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
3300 |
3 |
12.04 |
12.04 |
5906675464176 |
|
R-DRG-2875-V |
2.8 |
75 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
3300 |
3 |
12.88 |
12.88 |
5906675464183 |
|
R-DRG-3163-V |
3.1 |
63 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
3300 |
3 |
12.96 |
12.96 |
5906675464190 |
|
R-DRG-3175-V |
3.1 |
75 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
2200 |
2 |
10.32 |
10.32 |
5906675464206 |
|
R-DRG-3190-V |
3.1 |
90 |
Clipped head |
Ring |
Silver Galvanised |
Minimum 12 microns |
34º paper laminated |
44 |
2200 |
2 |
12.13 |
12.13 |
5906675464213 |
